| Pantera Transaxil Out Put RPM | ||||||||
| Engine RPM | Gear Box Out Put RPM Old 5th .705 [1] | Transaxil Output RPM 4.22 Ratio[2] | Inches per minute based on 315/35/17 with 25.68 inch dia. Circumference is 80.6760 inches | Convertion from inches per minute to MPH Conversion Factor .00094697 | ||||
| 1,000 | 1,418.44 | 336.12 | 27,117.07 | 25.68 | ||||
| 1,500 | 2,127.66 | 504.18 | 40,675.61 | 38.52 | ||||
| 2,000 | 2,836.88 | 672.25 | 54,234.14 | 51.36 | ||||
| 2,500 | 3,546.10 | 840.31 | 67,792.68 | 64.20 | ||||
| 2,600 | 3,687.94 | 873.92 | 70,504.39 | 66.77 | ||||
| 2,700 | 3,829.79 | 907.53 | 73,216.09 | 69.33 | ||||
| 2,800 | 3,971.63 | 941.14 | 75,927.80 | 71.90 | ||||
| 2,900 | 4,113.48 | 974.76 | 78,639.51 | 74.47 | ||||
| 3,000 | 4,255.32 | 1,008.37 | 81,351.22 | 77.04 | ||||
| 3,300 | 4,680.85 | 1,109.21 | 89,486.34 | 84.74 | ||||
| 3,500 | 4,964.54 | 1,176.43 | 94,909.75 | 89.88 | ||||
| 4,500 | 6,382.98 | 1,512.55 | 122,026.82 | 115.56 | ||||
| 5,500 | 7,801.42 | 1,848.68 | 149,143.89 | 141.23 | ||||
| 5,800 | 8,226.95 | 1,949.51 | 157,279.02 | 148.94 | ||||
| 6,000 | 8,510.64 | 2,016.74 | 162,702.43 | 154.07 | ||||
| 7,000 | 9,929.08 | 2,352.86 | 189,819.50 | 179.75 | ||||
| 7,500 | 10,638.30 | 2,520.92 | 203,378.04 | 192.59 | ||||
| Engine RPM | Gear Box Out Put RPM New 5th .642 | Transaxil Output RPM 4.22 Ratio | Inches per minute based on 315/35/17 with 25.68 inch dia. Circumference is 80.6760 inches | Convertion from inches per minute to MPH Conversion Factor .00094697 | MPH Increase .642 vs .705 5th gear | |||
| 1,000 | 1,557.63 | 369.11 | 29,778.09 | 28.20 | 2.52 | |||
| 1,500 | 2,336.45 | 553.66 | 44,667.14 | 42.30 | 3.78 | |||
| 2,000 | 3,115.26 | 738.21 | 59,556.19 | 56.40 | 5.04 | |||
| 2,500 | 3,894.08 | 922.77 | 74,445.23 | 70.50 | 6.30 | |||
| 2,600 | 4,049.84 | 959.68 | 77,423.04 | 73.32 | 6.55 | |||
| 2,700 | 4,205.61 | 996.59 | 80,400.85 | 76.14 | 6.80 | |||
| 2,800 | 4,361.37 | 1,033.50 | 83,378.66 | 78.96 | 7.06 | |||
| 2,900 | 4,517.13 | 1,070.41 | 86,356.47 | 81.78 | 7.31 | |||
| 3,000 | 4,672.90 | 1,107.32 | 89,334.28 | 84.60 | 7.56 | |||
| 3,300 | 5,140.19 | 1,218.05 | 98,267.71 | 93.06 | 8.32 | |||
| 3,500 | 5,451.71 | 1,291.88 | 104,223.32 | 98.70 | 8.82 | |||
| 4,500 | 7,009.35 | 1,660.98 | 134,001.42 | 126.90 | 11.34 | |||
| 5,500 | 8,566.98 | 2,030.09 | 163,779.51 | 155.09 | 13.86 | |||
| 5,800 | 9,034.27 | 2,140.82 | 172,712.94 | 163.55 | 14.62 | |||
| 6,000 | 9,345.79 | 2,214.64 | 178,668.56 | 169.19 | 15.12 | |||
| 7,000 | 10,903.43 | 2,583.75 | 208,446.65 | 197.39 | 17.64 | |||
| 7,500 | 11,682.24 | 2,768.30 | 223,335.70 | 211.49 | 18.90 | |||
| Conversion Equation | ||||||||
| Inches/Min X 1 ft/12 in X 60 min/1 hr X 1 mile/5,280Ft = .00094697MPH | ||||||||
|
|
||||||||
